| Place of Origin: | Cangzhou, China |
| Brand Name: | SOOME |
| Certification: | CE |
| Model Number: | SMHQ-LX-1800 |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wrapped with film or in wooden case |
| Delivery Time: | 30sets per month |
| Payment Terms: | T/T, L/C, Western Union |
| Usage: | Match With Production Line For Sheet Cutting | Working Width: | 1600 / 1800 / 2000 / 2200mm As Customer Need |
|---|---|---|---|
| Speed: | 100-130m / Min. | Knife Type: | Helical Knife Or Straight Knife As Customer Need |
| Knife Material: | Hard Steel With Tungsten Carbide On Edge | Machine Color: | Customized |
| Machine Layers: | One Or Two Layers | Electrics Brand: | Delta / MCGS / Inovance |
| Voltage: | 220 / 380 / 415V | Warranty: | One Year |
| High Light: | corrugated sheet cutting machine,sheet board cutting machine |
||
Helical Blade Corrugated Rotary Die Cutter , Reel To Sheet Cutting Machine
I. Functions and characteristics
1. With single or double layers structure for choice.
2. Colorful touch screen display all kinds of production information which can be checked, revised ,added or canceled.
3. Special structural design, particularly well mechanical strength wall and base.
4. Special high-speed helical cutter for cutting cardboard smooth without burr.
5. Blade adjustment and changing design, fast and convenient.
6. Drive box adopts oil pump type high precision gear drive with low noise, steady.
7. AC servo motor driven cutting, high efficiency, high precision.
8. Transport out of paper using an independent variable frequency motor drive, and line speed synchronization.
9. AC servo control system, energy saving 30%.
10. Computers can store multiple sets of orders,changing orders automatically with non-stop, and to achieve computing network to facilitate the production management.
11. Cutting length range ;500-9999mm; Cutting accuracy; ± 1mm.
12. The speed : 5０－130m/min
13. Valid breadth:1400mm-2500mm.
II. Technical parameters
| Model | SMHQ-LX-1600 | SMHQ-LX-1800 |
| Effective working width | 1600mm | 1800mm |
| Wallboard inner width | 1800mm | 2000mm |
| Design speed | 130m/min | 130m/min |
| Economic speed | 90~110m/min | 90~110m/min |
| Machine size | 3300x1300x1560mm | 3500x1300x1560mm |
| Operation cabinet size | 1000x600x1400mm | 1000x600x1400mm |
III. FAQ
1. Where is your factory located?
A: Our factory is in Dongguang county, Cangzhou city, Hebei, China.
2. Will you attend Corrugated Packaging Exhibition?
A: Yes, we attend the Sinco Corrugated Expro every year. One year in Shanghai and next year in Dongguan, Guangdong province.
3. Can customer visit SOOME factory?
A: Yes, welcome to visit our factory anytime. Can contact us before your coming.
