Servo Motor Folder And Gluer Machine Cardboard Automatic Folder Gluer Stitcher

Place of Origin Made In China
Brand Name SOOME
Certification CE
Model Number SMZX-BZD-2600
Minimum Order Quantity 1 Set
Price Negotiation
Packaging Details Wapped With Film
Delivery Time 2 Months
Payment Terms L/C, T/T, Western Union
Supply Ability 50 Sets/Month
Product Details
Type Gluing Machine Total Power 3KW
Driven Type Electric Warranty 1 Year
Weight 2.15T Height Of Feeder 1M
Material Steel Usage For Paper Gluing
High Light

folding and gluing machine


folder and gluer machine

Leave a Message
Product Description

Servo Motor Folder And Gluer Machine Cardboard Automatic Folder Gluer Stitcher




The gluing box machine is a mechanical equipment used for folding folding cartons in a carton factory. It is divided into two types: folding and folding. The gluing box machine is generally composed of a feeding part, a rectifying part, a mark shaping part, a glue coating part, a folding part and a counting discharge part. In general, the adhesive box machine refers to the whole process of the corrugated cardboard which is completed by the machine. It does not include a simple coating device which is folded and corrected by manpower. The front end of the sticky box machine can be connected to the print or the printed slotting die cutting machine. The back end of the stick box machine can connect the full automatic baling machine and the full automatic stacker, so that the production line of the corrugated carton can be produced, which greatly improves the production efficiency and reduces the production cost.Semi automatic gluing machine is a mechanical device that needs to be manually involved in part of the carton forming process. Semi automatic sticky box machine can not be used together with the production line of carton.




1. Imported dual servo motors, high precision, decreased the mechanical driving parts and malfunction.

2. Touch screen control the parameters (nails distance, nails qty/type, back baffles), changing fast and convenient.

3. Back electrical baffle adopt stepper motor, accurate and fast.

4. The complete stitching head adopts special steel with precise processing.

5. Carton sizes and nails distance changing time need 1 minute, save more time.

6. Can stitch intensive nails, single nail, double rows nail, finish in one time.

7. Front paper feeding part is automatic counting, settled with photoelectric sensor, can lift up automatically when feeding paper.

8. Last section has automatic counting function, finished cartons can be piled as per the pre-set qty (1~99) and convey out for easy packing.

9. Will warn automatically when the brass wires finished.

10. Max. speed:600 nails/min.


Model   SMZX-BZD-2600
Max size (L+W)*2 2600mm
Min size (L+W)*2 340mm
Max size(W+H)*2 1500mm
Min size (W+H)*2 260mm
Height of feeder 1000mm
Power 4kw
Machine length 5300mm
Machine weight 2150kg
Machine speed 60m/min
