Place of Origin: | HEBEI CHINA |
Brand Name: | SOOME |
Certification: | CE |
Model Number: | SMHQ |
Minimum Order Quantity: | 1 Set |
---|---|
Price: | Contact |
Packaging Details: | Wooden case or plastic film 1*20'' container by shipping from Tianjin port |
Delivery Time: | 35 Days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 15 set / month |
Type: | Servo Type | Usage: | Cutting Corrugated Sheet |
---|---|---|---|
Speed: | 130-150m/min | Driven Type: | Electric |
Weight: | 5000KG | Warranty: | 1 Year |
Highlight: | corrugated cardboard cutter,corrugated sheet cutting machine |
NC Spiral Blade Rotary Die Cutting Machine For Corrugated Boxes 130 M/Min
Functions and characteristics:
1. With single or double layers structure for choice.
2. Colorful touch screen display all kinds of production information which can be checked, revised ,added or canceled.
3. Special structural design, particularly well mechanical strength wall and base.
4. Special high-speed helical cutter for cutting cardboard smooth without burr.
5. Blade adjustment and changing design, fast and convenient.
6. Drive box adopts oil pump type high precision gear drive with low noise, steady.
7. AC servo motor driven cutting, high efficiency, high precision.
8. Transport out of paper using an independent variable frequency motor drive, and line speed synchronization.
9. AC servo control system, energy saving 30%.
10. Computers can store multiple sets of orders,changing orders automatically with non-stop, and to achieve computing network to facilitate the production management.
11. Cutting length range ;500-9999mm; Cutting accuracy; ± 1mm.
12. The speed : 50-130m/min
13. Valid breadth:1400mm-2500mm.
SMHQ-LX-1600 | SMHQ-LX-1800 | |
Effective working width | 1600mm | 1800mm |
Wallboard width | 1800mm | 2000mm |
Design speed | 130m/min | 130m/min |
Economic speed | 90~110m/min | 90~110m/min |
Machine size | 3300x1300x1560mm | 3500x1300x1560mm |
Operation cabinet size | 3500x1300x1560mm | 1000x600x1400mm |
Whichever phase you are in,we are always around you Ever-lasting service system.
Pre-sales service
1. We can provide customers with a variety of production processes programs free of charge,including technical advice,equipment selection,customization according to special requirements of customers and make appropriate adjustments.
Installation and debugging
2. While delivering equipment to the customer on time,we will send technical service engineers for on site installation.Under the conditions that the customer’s sites are available for the installation and debugging of spare parts,our technical service engineers will complete the installation and debugging of the equipment orderly within a short time for customer use.
Technical training
3. We provide free technical training.After the installation and debugging is completed at the user’s site,we will conduct the training for user’s operation with 1-2 maintenance personnel respectively.The training includes the machine principle,equipment structure,process description,equipment maintenance,safety protection,operational procedures,simple troubleshooting etc.
Equipment maintenance
4. We provide users with comprehensive after-sales services.
Commitment:1 year warranty since the date of equipment installation and debugging are qualified.If equipment has operation failure,the company promises to provide users with solutions within 24 hours.After the warranty expiration,the company provides the lifetime maintenance services.
5. We provide free technical training.After the installation and debugging is completed at the user’s site,we will conduct the training for user’s operation with 1-2 maintenance personnel respectively.The training includes the machine principle,equipment structure,process description,equipment maintenance,safety protection,operational procedures,simple troubleshooting etc.
Soome Machine,established in 1995.Specialized in developing and manufacturing the automatic,high speed,precise and good quality corrugated machines.We provide the whole dry-end solution for corrugated production line slitter scorer and touch line indentation machine .
Facing the fierce competition in corrugated packing field,our company adopt three concepts"mechanotronics""intelligent operation"and"simple usage".We developed several new high speed automatic machines which improved the competition ability of our customers.
We got the recognition of thousands packing companies from domestics and overseas based on the principle of honest and trustworthy.Our products sold to Italy,Argentina,Russian,India,Pakistan,Germany,Egypt,Vietnam,Kazakhstan,Iran,Turkey,Spain and so on.
Wish we unite in a concerted effort for the beautiful future!
