1t/Hour 1500 Gear Drive Carton Box Shredder Machine For Waste Paper Packing Station
Voltage | Customer's Demand | Usage | Waste Corrugated Paper Shredder And Baler |
---|---|---|---|
Output | 1000Kg/hour | Apply To Industry | Retail, Recycling And Reuse |
Power | 15kw | Type Of Shipping | By Sea Or By Land |
Machine Weight | 3000Kg | Using Industry | Corrugated Box Factory,waste Paper Baling Station |
High Light | gear drive carton box shredder machine,computerized carton box shredder machine,gear drive corrugated box shredder machine |
1T/hour 1500 Carton Recycling Shredder For Waste Paper Packing Station
Scope of application:
Waste paper shredder commonly used in all kinds of waste paper tubes and corrugated cardboard that are not processed,squeeze each other through the shear of the shredder,shredder Sheet materials that meet the requirements.This series of shredder has a strong commonality,standard modular design is adopted,good interchangeability of parts and components.Blade adopt special alloy steel made by special process,has the characteristics of wear resistance and mild high.Cutter shaft low speed,low noise and low energy consumption.
The driving part adopts intermediate gear drive,form a differential relationship.The appearance is beautiful and generous, the structure is precise and compact.
Working principle
The material is evenly distributed by hand and sent to the tearing room in moderation. Under the action of tearing knife, all kinds of paper tube and paperboard are torn into flake material, and under the action of fan, they enter the fan, then crush it twice through the fan, and then send it directly through the conveying pipe to the aggregate room by the wind pressure.
Multifunctional shredder | Host | Host equipped with a fan |
Outline dimension | 2200*1650*1800 | 2200*3500*1800 |
Wallboard in the width | 250*1500 | 250*1500 |
Working range | 90-250mm | 90-250mm |
Motive power | 15KW | 15KW |
Quantity of production | 1T/hour | 1T/hour |
Weight | 3T | 4T |
Material receiving type | Manual receiving | Receiving port |
Feeding type | Manual feeder | Shredder fan |
Angle head |
