Width 1400-2200mm Corrugated Automatic Machine Spiral Cut Off Blade Knife Cross Cut Carton
Place of Origin | Hebei Province China |
---|---|
Brand Name | SOOME |
Certification | CE Certification |
Model Number | NC-1800 |
Minimum Order Quantity | 1 SET |
Price | Negotiation |
Packaging Details | wooden case and filing with plastic film |
Delivery Time | 10 days after depoist |
Payment Terms | L/C, T/T, Western Union |
Supply Ability | 80 per/mounth |
Warranty | 3 Month | Classification | Helical Knife |
---|---|---|---|
Weight | 23 KG/PCS | Blade Length | Customize |
High Light | width 2200mm corrugated automatic machine,helical knife corrugated automatic machine,width 1400mm automatic corrugation machine |
Width 1400-2200mm Spiral Cut Off Blade Knife Cross Cut Corrugated Carton
Machine intruction:
1. It can store 200 units orders,replace the cutter specifications quickly and accurately,changing orders without stop,And enables networked computers to facilitate production management.
2. Knife shaft drive gears are precision forged steel induction hardening, backlash-free transmission, advanced keyless connection, high transmission accuracy.
3. Cutting machine adopts inlaid front steel blade knife spiral structure, serrated knife. scissors, shears, shear force, long blade life.
5. Exact and adjustable no gap gear to ensure precise blade engagement, running balance.
6. Knife roller: fine quality forged steel material, the balanced, with good stability.
8. Cutting length: 500mm-9000mm, cutting precision: ± 1mm (at steady speed).
Technical specification:
Specification for Taiwan Chinese, German Corrugated Machine
|
|
2840/2540*30*8
|
2600*35/32*10/8
|
2640.8*31.65/31.2*9.5/8
|
2600*42.5/52*10
|
2580/2280*38/36*13/10
|
2300*40.5*10
|
2900/2600/2300/1900*38/35.5*10
|
2300*39/37*10
|
2640/2340/1940*31/32*8/9.7
|
2300*38*10
|
2900*40/36*10
|
2300*50*12
|
2600/2300/1900*42.5/52*10
|
2300*40/36*10
|
2300/1900*42.5/45*10
|
1500*39*8
|
Features:
1. Customized Size:suitable for all Chinese German brand corrugated machines
2. Customized Material: Competitive & Top Quality Material for you to select
3. Sharp Edge,No Burr:High Precision Grinding Machine for Fine Grinding
4. Low MOQ & Large Inventory &Fast Dispatch
