Carton Box 250m/Min 7 Ply Corrugated Cardboard Plant
Product Details:
Place of Origin: Hebei China
Brand Name: Soome
Model Number: SM-2200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: contrat
Packaging Details: film or plastic
Delivery Time: 30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2set per year
Contact Now
Detailed Product Description
Certification: CE Name: Cardboard Product Line
Usage: Cardboard Making Function: Corrugated Cardboard Making
Speed: 250m/min Automatic Grade: Automatic Grade
Voltage: 220/380/440V Condition: New Condition
Type: 3&5&7 Ply High Speed Corrugated Cardboard Production Line Driven Type: Electric
Packaging Type: Film Power: 400kw
High Light:

carton box corrugated cardboard plant

,

250m/min corrugated cardboard plant

,

7 ply corrugated cardboard plant

Second Hand 7 ply 2200mm Corrugated Paperboard Production Line

Use for corrugated paperboard making machine

Second hand high speed corrugated line



specification



Equipment name



UN IT



QT Y



Remark



ZJ-V6B

Hydraulic shaftless mill roll

stand



a



7



Cardboard Production Line Plant

Spindle ¢270mm, hyperbolic heavy rocker, toothed chuck , multi-point brake, hydraulic drive lifting, panning left and right on the middle.





YXC



Hydraulic pressurePap er system





a





14





Cardboard Production Line Plant

Double groove width 10m. guide rail length and the ground level, on the double position paper design, hydraulic clamp for paper, paper unloading hydraulic push rod save manpower, hydraulic motor traction

feeding trolley.



JZJ



Automatic splicer



a



7



Cardboard Production Line Plant

Automatic splicer keep corrugating cardboard assembly line uninterrupted work,Reduce paper consumption,Greatly improve productivity.Maximum

speed 250m/min



RG-1-1000

Top paper preheat cylinder



a



3



Cardboard Production Line Plant

roller ¢1000mm,including pressure container certificate.Electric adjustment wrap angle.Wrap angle can adjust the paper preheat area in the range of

360°.



RG-1-1000

Core paper preheat cylinder



a



3



Cardboard Production Line Plant

roller ¢1000mm,including pressure container certificate.Electric adjustment wrap angle.Wrap angle can adjust the paper preheat area in the range of

360°.





SF-500A



Multi-casset te positive pressure single facer





a





3





Cardboard Production Line Plant

Main corrugating roller ¢500mm,corrugating roller group flute quick change.corrugated roller with spraying tungsten carbide dealing.with

maintenance-free airbag loading,PLC automatic control glue, HMI touch screen, Breaks automatic

parking relief.





DY-C

Electric hydraulic roller change

forklift





set





1





Cardboard Production Line Plant



Large capacity battery, power walking, hydraulic lift, centralized control.



RG-4-1060



Triple preheater



a



1



Cardboard Production Line Plant

roller ¢1060mm,including pressure container certificate.Electric adjustment wrap angle.Wrap angle can adjust the paper preheat area in the range of

360°.





GM-30

Double glue machine

(heavy

type)





a





1





Cardboard Production Line Plant



Glue roller diameter 320mm.Frequency motor drive, PLC control. Glue quantity PCL automatic adjustment,HMI touch screen display.



TQ-I

Conveyor bridge



set



1



Cardboard Production Line Plant

200mm main beam channels, independent inverter motor drive pull paper feed, adsorption

tension.Electric correction.





XG-JP





Automatic correction





set











Cardboard Production Line Plant

No power correction model save energy.High precision sheet correction. Paper width change does not require any adjustment

Full width infrared detection curtain.Reduce paper

waste generated tear.reduce the waste of paper edge not to precision.



DQD

Ear cut machine



set



1



Cardboard Production Line Plant

Cut off bad cardboard when start working, when slit

change order cut the sides automatically,make the waste come into the suction opening automatically.









SM-E2









Double facer









set









1









Cardboard Production Line Plant

Rack 400 mm GB channel,Chrome hot plate600 mm

*20pieces,Entrance ¢ 400mm hot cylinder of top paper speed raised temperature,16groups whole contact plate design construction.PLC automatic control press plate.Up and down with automatic correction, temperature display, frequency motor.Adopt PID automatic temperature control system, link with raw pipe three layers, five layers automatically control the number of temperature hot plates, high

efficiency and energy saving





NCBD



NC thin blade slitter scorer





a





2





Cardboard Production Line Plant

Tungsten alloy steel, seven knives twelve lines, zero-pressure line type. Schneider servo computer automatically discharge knife, suction outlet width automatically adjusted.Closed electric control box,

plus air conditioning dehumidification



NC-30D

Double NC cutter helical knives



a



1



Cardboard Production Line Plant

Full AC servo control, energy storage brake, helical blade structure, oil-immersed gears,10.4-inch touch screen display.Closed electric control box, plus air

conditioning dehumidification





NC-DL

Double Automatic large down stacking

machine





a





1





Cardboard Production Line Plant

Five sections of the high-strength belt conveyor, frequency loop control,automatic points precision, row single-cycle 20 seconds,stacking length1800mm, HMI touch screen.
ZJZ Automatic Glue station set 1 Cardboard Production Line Plant Customers -owned pipeline . Glue configuration is composed by carrier tank,main tank,storage tank,



Carton Box 250m/Min 7 Ply Corrugated Cardboard Plant 0Carton Box 250m/Min 7 Ply Corrugated Cardboard Plant 1

Carton Box 250m/Min 7 Ply Corrugated Cardboard Plant 2

Structural features:



★surface of hot plate is dealed with grinding, hot plate width600mm,in total 20 pieces hot plate,Minister cooling stereotypes 5m.

Hot plate is made adopt container board, enclosed pressure container certificate and inspection certificate.Internal thermal panels for partition isolation structure,s-shaped flow of steam, Steam, water separation function apparent,improve the using rate of steam.

★upper conveying belt adopt pneumatic correction.

★ piping thermal heating plate temperature control points four sections with temperature display.

★upper conveying belt adopt pneumatic correction.

★Drive roller coated with wear-resistant rubber attached, and with the high output ensure smooth cardboard.

★Gearbox drive unit using an independent structure, gear steel ZG-500 number for materials, the use of oil-immersed gear lubrication.

★Electrical components used internationally renowned brands, the device stable and reliable operation.

★Main drive motor for the motor frequency energy, low-speed torque, wide speed range, reliable, easy maintenance.

★The main backbone of high intensity profiles GB, solid structure, beautiful appearance, suitable for high speed working.



technical parameters:

1. MAX effective width:2500mm

2. operation direction:left or right(determined in accordance with customer’s factory building)

3. MAX machinery speed:300m/min

4. temperature range:160—200℃

steam pressure:0.8-1.3Mpa

5. air source pressure: 0.6—0.9Mpa

6. quantity of heat plate:20 pieces Cooling stereotypes length:5m

roller diameter parameters:

1. up drive rubber roller diameter:¢800mm bottom drive rubber roller diameter: ¢600mm outsourcing wear rubber

2. Former follower with roller diameter:¢215mm After setting the driven belt rollers diameter :¢215mm

3. pressure belt roller diameter: ¢70mm Shaping roller diameter:¢86mm
